Atomic resolution image of a highly branched ruthenium nanoparticle, taken using an aberration-corrected transmission electron microscope (AC-TEM) at the Center for Integrated Nanotechnologies (CINT).
Atomic resolution image of a highly branched ruthenium nanoparticle, taken using an aberration-corrected transmission electron microscope (AC-TEM) at the Center for Integrated Nanotechnologies (CINT).
Image courtesy of John Watt, Center for Integrated Nanotechnologies, Los Alamos National Laboratory

The Science

Catalysis is the process of speeding up a chemical reaction; it’s very important for many technologies. Branched nanoparticles are one of the most promising catalysts. Scientists can control their branch sizes and surfaces to make them more stable and more effective catalysts. By creating branched nanoparticles from the metal ruthenium, researchers developed a way to increase the speed of catalysis while maintaining the catalyst’s stability. Because they have precise control over the nanoparticle’s crystal structure, they can create a reaction that is both highly active and highly stable.

The Impact

Ruthenium nanoparticles have the potential to be an important catalyst for producing hydrogen fuel. (Nanoparticles are particles that are less than 100 nanometers, which is about one-thousandth the width of a human hair.) However, most of the time, the ruthenium dissolves in the first few cycles. This work shows that it is possible for scientists to control the ruthenium’s crystal structure. This could allow them to improve how well ruthenium performs in hydrogen fuel cells. In addition, researchers can apply these principles to a range of different metal nanoparticles. That information will help them create nanocatalysts with high levels of activity and stability.

Summary

It is vital to understand how the crystallinity and surface facets of branched nanoparticles affect catalysts’ performance. One context for such performance is splitting water for hydrogen fuel production. This process involves an anodic reaction (where electrons flow from the fuel cell’s anode) called the oxygen evolution reaction. Ruthenium nanoparticles are the most active catalyst for this reaction. However, their use is limited because typically the ruthenium will completely dissolve in the first few reaction cycles. There is some evidence that scientists could reduce the dissolution by using ruthenium metal surfaces with low energy crystal faces. Such nanoparticles are both stable and active, and they are a key target for oxygen evolution reaction catalysts. This team has made an important advance toward this target by synthesizing and characterizing branched ruthenium nanoparticles with precise control over crystallinity. The team designed the nanoparticles with two critical features: a high surface area, which increases catalytic activity, and low-energy crystal surfaces, which greatly increases catalytic stability. They found that, by using low ratios of the organic molecules that are used to direct the growth of the nanoparticles, they were able to achieve their goal of long, highly crystalline branches with low energy surfaces. The nanoparticles had much better stability and a five-fold increase in reaction activity compared to polycrystalline ruthenium nanoparticles. This work highlights the importance of synthetically controlling nanoparticle crystallinity to optimize surface properties for electrocatalysis.

Contact

John Watt
Center for Integrated Nanotechnologies, Los Alamos National Laboratory
watt@lanl.gov

Dale Huber
Center for Integrated Nanotechnologies, Sandia National Laboratories
dlhuber@sandia.gov

Funding

A.R.P. is supported by an Australian Government Research Training Program Scholarship and the UNSW Scientia PhD Scholarship Scheme. L.G., J.J.G., and R.D.T acknowledge funding under the Australian Research Council Linkage grant. Support from the Australian Research Council through the award of an Australian Laureate Fellowship for J.J.G and a Discovery Project for R.D.T. are acknowledged. This research used the facilities supported by Microscopy Australia (formerly AMMRF) at the Electron Microscope Unit at UNSW. This work was performed, in part, at the Center for Integrated Nanotechnologies (CINT), an Office of Science User Facility operated for the U.S. Department of Energy (DOE), Office of Science.

Publications

A.R. Poerwoprajitno, et al., “Formation of Branched Ruthenium Nanoparticles for Improved Electrocatalysis of Oxygen Evolution Reaction.” Small 15 (17), 1804577 (2019). [DOI: 10.1002/smll.201804577]
